Model "Farm Yard". Vector plan for CNC.
Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)
Sizes:
3 mm thickness: 240 x 432 x 115 mm (9,45 x 17,01 x 4,53'')
1/8''(3.175mm) thickness: 254 x 457 x 122 mm (10,00 x 18,00 x 4,79'')
4 mm thickness: 320 x 576 x 153 mm (12,60 x 22,68 x 6,04'')
6 mm thickness: 480 x 864 x 230 mm (18,90 x 34,02 x 9,06'')
1/4''(6.35mm) thickness: 508 x 914 x 243 mm (20,00 x 36,00 x 9,58'')
Work area:
3 mm thickness: 893 x 467 mm (35,16 x 18,39'')
1/8''(3.175mm) thickness: 945 x 494 mm (37,21 x 19,46'')
4 mm thickness: 1191 x 623 mm (46,88 x 24,51'')
6 mm thickness: 1786 x 934 mm (70,31 x 36,77'')
1/4''(6.35mm) thickness: 1890 x 988 mm (74,42 x 38,92'')
Biggest part:
3 mm thickness: 442 x 240 mm (17,40 x 9,45'')
1/8''(3.175mm) thickness: 468 x 254 mm (18,42 x 10,00'')
4 mm thickness: 589 x 320 mm (23,20 x 12,60'')
6 mm thickness: 884 x 480 mm (34,80 x 18,90'')
1/4''(6.35mm) thickness: 936 x 508 mm (36,83 x 20,00'')
In the file:
blue color - engrave
pink color - cut
black color - cut
What you receive:
You will download 1 ZIP files containing the following:
the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instructions
Version for Glowforge laser machine available only for 1/8'' and 3mm material thickness.
If you have any questions feel free to contact me:)
