Tiered Display stand - 3 tiers- laser cut file

Laser cut design "Display Stand". Vector plan for CNC.

Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)

Sizes:

3 mm thickness: 153 x 232 x 229 mm (6,02 x 9,13 x 9,02'')

1/8''(3.175mm) thickness: 162 x 246 x 242 mm (6,38 x 9,67 x 9,54'')

4 mm thickness: 204 x 309 x 305 mm (8,03 x 12,18 x 12,02'')

6 mm thickness: 306 x 464 x 458 mm (12,05 x 18,27 x 18,03'')

1/4''(6.35mm) thickness: 324 x 491 x 485 mm (12,75 x 19,33 x 19,08'')

Work area:

3 mm thickness: 814 x 234 mm (32,05 x 9,21'')

1/8''(3.175mm) thickness: 861 x 248 mm (33,92 x 9,75'')

4 mm thickness: 1085 x 312 mm (42,73 x 12,28'')

6 mm thickness: 1628 x 468 mm (64,09 x 18,43'')

1/4''(6.35mm) thickness: 1723 x 495 mm (67,83 x 19,50'')

Biggest part:

3 mm thickness: 153 x 232 mm (6,02 x 9,13'')

1/8''(3.175mm) thickness: 162 x 246 mm (6,38 x 9,67'')

4 mm thickness: 204 x 309 mm (8,03 x 12,18'')

6 mm thickness: 306 x 464 mm (12,05 x 18,27'')

1/4''(6.35mm) thickness: 324 x 491 mm (12,75 x 19,33'')

In the file:

pink color - cut

black color - cut

What you receive:

You will download 1 ZIP files for 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) containing the following:

the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instruction

If you have any questions feel free to contact me:)
