Laser cut design "Siege weapons (Siege tower & ram) of the Castle Set". Vector plan for CNC laser machines, Glowforge.
This is one of the blocks of the Castle. In the future, I plan to expand this design and create many additions for it (towers, walls, gates, bridges, etc.) that can be combined with each other.
You will be able to design and connect these blocks to create a wide variety of the castles.
Watch for new additions in my store in a separate category "Castle set" or just text in the search field "Castle" to see everything that is available at the moment
Also you can see full blocks of the Castle designs by this link
https://designbundles.net/vectorpainter/castle-set
Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)
Sizes:
3 mm thickness: 50 x 57 x 84 mm (1,97 x 2,24 x 3,31'')
1/8''(3.175mm) thickness: 53 x 60 x 89 mm (2,08 x 2,38 x 3,50'')
4 mm thickness: 67 x 76 x 112 mm (2,62 x 2,99 x 4,41'')
6 mm thickness: 100 x 114 x 168 mm (3,94 x 4,49 x 6,61'')
1/4''(6.35mm) thickness: 106 x 121 x 178 mm (4,17 x 4,75 x 7,00'')
Work area:
3 mm thickness: 387 x 83 mm (15,24 x 3,27'')
1/8''(3.175mm) thickness: 410 x 88 mm (16,13 x 3,46'')
4 mm thickness: 516 x 111 mm (20,31 x 4,36'')
6 mm thickness: 774 x 166 mm (30,47 x 6,54'')
1/4''(6.35mm) thickness: 819 x 176 mm (32,25 x 6,92'')
Biggest part:
3 mm thickness: 53 x 81 mm (2,09 x 3,19'')
1/8''(3.175mm) thickness: 56 x 86 mm (2,21 x 3,38'')
4 mm thickness: 71 x 108 mm (2,78 x 4,25'')
6 mm thickness: 106 x 162 mm (4,17 x 6,38'')
1/4''(6.35mm) thickness: 112 x 171 mm (4,42 x 6,75'')
In the file:
green color - draw (cut with little power and big speed)
red color - cut
black color - cut
What you receive:
You will download 1 ZIP files for 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) containing the following:
the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instruction
If you have any questions feel free to contact me:)
