Model "Main Gate of the Castle". Vector plan for CNC.
This is one of the blocks of the castle. In the future, I plan to expand this design and create many additions for it (towers, walls, gates, bridges, etc.) that can be combined with each other.
You will be able to design and connect these blocks to create a wide variety of the castles.
Watch for new additions in my store in a separate category "Castle set" or just text in the search field "Castle" to see everything that is available at the moment
Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)
Sizes:
3 mm thickness: 102 x 110 x 214 mm (4,02 x 4,33 x 8,43'')
1/8''(3.175mm) thickness: 108 x 116 x 226 mm (4,25 x 4,58 x 8,92'')
4 mm thickness: 136 x 147 x 285 mm (5,35 x 5,77 x 11,23'')
6 mm thickness: 204 x 220 x 428 mm (8,03 x 8,66 x 16,85'')
1/4''(6.35mm) thickness: 216 x 233 x 453 mm (8,50 x 9,17 x 17,83'')
Work area:
3 mm thickness: 420 x 239 mm (16,54 x 9,41'')
1/8''(3.175mm) thickness: 445 x 253 mm (17,50 x 9,96'')
4 mm thickness: 560 x 319 mm (22,05 x 12,55'')
6 mm thickness: 840 x 478 mm (33,07 x 18,82'')
1/4''(6.35mm) thickness: 889 x 506 mm (35,00 x 19,92'')
Biggest part:
3 mm thickness: 76 x 136 mm (2,99 x 5,35'')
1/8''(3.175mm) thickness: 80 x 144 mm (3,17 x 5,67'')
4 mm thickness: 101 x 181 mm (3,99 x 7,14'')
6 mm thickness: 152 x 272 mm (5,98 x 10,71'')
1/4''(6.35mm) thickness: 161 x 288 mm (6,33 x 11,33'')
In the file:
green color - draw (cut with little power and big speed)
pink color - cut
black color - cut
What you receive:
You will download 1 ZIP files for 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) containing the following:
the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instruction
