Garage with opened door - laser cut file, SVG DXF AI CDR

Laser cut design "Garage". Vector plan for CNC.

Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)

Sizes:

3 mm thickness: 270 x 143 x 134 mm (10,63 x 5,63 x 5,28'')

1/8''(3.175mm) thickness: 286 x 151 x 142 mm (11,25 x 5,96 x 5,58'')

4 mm thickness: 360 x 191 x 179 mm (14,17 x 7,51 x 7,03'')

6 mm thickness: 540 x 286 x 268 mm (21,26 x 11,26 x 10,55'')

1/4''(6.35mm) thickness: 572 x 303 x 284 mm (22,50 x 11,92 x 11,17'')

Work area:

3 mm thickness: 842 x 284 mm (33,15 x 11,18'')

1/8''(3.175mm) thickness: 891 x 301 mm (35,08 x 11,83'')

4 mm thickness: 1123 x 379 mm (44,20 x 14,91'')

6 mm thickness: 1684 x 568 mm (66,30 x 22,36'')

1/4''(6.35mm) thickness: 1782 x 601 mm (70,17 x 23,67'')

Biggest part:

3 mm thickness: 286 x 115 mm (11,26 x 4,53'')

1/8''(3.175mm) thickness: 303 x 122 mm (11,92 x 4,79'')

4 mm thickness: 381 x 153 mm (15,01 x 6,04'')

6 mm thickness: 572 x 230 mm (22,52 x 9,06'')

1/4''(6.35mm) thickness: 605 x 243 mm (23,83 x 9,58'')

In the file:

green color - draw (cut with little power and big speed)

pink color - cut

black color - cut

What you receive:

You will download 1 ZIP files for 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) containing the following:

the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instruction

If you have any questions feel free to contact me:)
