Big barn - laser cutting file, Horse stable, CNC plan

Model "Big barn". Vector plan for CNC.

Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)

Sizes:

3 mm thickness: 200 x 271 x 200 mm (7.87 x 10.67 x 7.87'')

1/8''(3.175mm) thickness: 212 x 287 x 212 mm (8.33 x 11.29 x 8.33'')

4 mm thickness: 267 x 361 x 267 mm (10.50 x 14.23 x 10.50'')

6 mm thickness: 400 x 542 x 400 mm (15.75 x 21.34 x 15.75'')

1/4''(6.35mm) thickness: 423 x 574 x 423 mm (16.67 x 22.58 x 16.67'')

Work area:

3 mm thickness: 490 x 272 mm (19.29 x 10.71'')

1/8''(3.175mm) thickness: 519 x 288 mm (20.42 x 11.33'')

4 mm thickness: 653 x 363 mm (25.72 x 14.28'')

6 mm thickness: 980 x 544 mm (38.58 x 21.42'')

1/4''(6.35mm) thickness: 1037 x 576 mm (40.83 x 22.67'')

Biggest part:

3 mm thickness: 250 x 200 mm (9.84 x 7.87'')

1/8''(3.175mm) thickness: 265 x 212 mm (10.42 x 8.33'')

4 mm thickness: 333 x 267 mm (13.12 x 10.50'')

6 mm thickness: 500 x 400 mm (19.69 x 15.75'')

1/4''(6.35mm) thickness: 529 x 423 mm (20.83 x 16.67'')

In the file:

pink color - cut

black color - cut

What you receive:

You will download 1 ZIP files for 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) containing the following:

the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instruction

If you have any questions feel free to contact me:)
