Model "Water tower". Vector plan for CNC.
Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)
Sizes:
3 mm thickness: 124 x 124 x 315 mm (4.88 x 4.88 x 12.40'')
1/8''(3.175mm) thickness: 131 x 131 x 333 mm (5.17 x 5.17 x 13.13'')
4 mm thickness: 165 x 165 x 420 mm (6.51 x 6.51 x 16.54'')
6 mm thickness: 248 x 248 x 630 mm (9.76 x 9.76 x 24.80'')
1/4''(6.35mm) thickness: 262 x 262 x 667 mm (10.33 x 10.33 x 26.25'')
Work area:
3 mm thickness: 615 x 320 mm (24.21 x 12.60'')
1/8''(3.175mm) thickness: 651 x 339 mm (25.63 x 13.33'')
4 mm thickness: 820 x 427 mm (32.28 x 16.80'')
6 mm thickness: 1230 x 640 mm (48.43 x 25.20'')
1/4''(6.35mm) thickness: 1302 x 677 mm (51.25 x 26.67'')
Biggest part:
3 mm thickness: 100 x 191 mm (3.94 x 7.52'')
1/8''(3.175mm) thickness: 106 x 202 mm (4.17 x 7.96'')
4 mm thickness: 133 x 255 mm (5.25 x 10.03'')
6 mm thickness: 200 x 382 mm (7.87 x 15.04'')
1/4''(6.35mm) thickness: 212 x 404 mm (8.33 x 15.92'')
In the file:
pink color - cut
black color - cut
What you receive:
You will download 1 ZIP files for 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) containing the following:
the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instruction
If you have any questions feel free to contact me:)
