Model "Nativity barn #1". Vector plan for CNC.
Material thickness: 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm)
Sizes:
3 mm thickness: 235 x 160 x 137 mm (9,25 x 6,30 x 5,39'')
1/8''(3.175mm) thickness: 249 x 169 x 145 mm (9,79 x 6,67 x 5,71'')
4 mm thickness: 313 x 213 x 183 mm (12,34 x 8,40 x 7,19'')
6 mm thickness: 470 x 320 x 274 mm (18,50 x 12,60 x 10,79'')
1/4''(6.35mm) thickness: 497 x 339 x 290 mm (19,58 x 13,33 x 11,42'')
Work area:
3 mm thickness: 733 x 309 mm (28,86 x 12,17'')
1/8''(3.175mm) thickness: 776 x 327 mm (30,54 x 12,88'')
4 mm thickness: 977 x 412 mm (38,48 x 16,22'')
6 mm thickness: 1466 x 618 mm (57,72 x 24,33'')
1/4''(6.35mm) thickness: 1552 x 654 mm (61,08 x 25,75'')
Biggest part:
3 mm thickness: 235 x 160 mm (9,25 x 6,30'')
1/8''(3.175mm) thickness: 249 x 169 mm (9,79 x 6,67'')
4 mm thickness: 313 x 213 mm (12,34 x 8,40'')
6 mm thickness: 470 x 320 mm (18,50 x 12,60'')
1/4''(6.35mm) thickness: 497 x 339 mm (19,58 x 13,33'')
In the file:
green color - draw (cut with little power and big speed)
pink color - cut
black color - cut
What you receive:
You will download 1 ZIP files for 3mm, 1/8''(3.175mm), 4mm, 6mm, 1/4''(6.35mm) containing the following:
the CDR, DXF, AI and SVG file for laser cutting and PDF-assembly instruction
If you have any questions feel free to contact me:)
